Features
1.The dust is inhaled and then filtered through the PTFE filter cartridge. The dust is blocked on the outer surface of the filter, and the clean air will be discharged.
2.No vibration, low noise dust removal and low air friction resistance can be achieved through reasonable mechanical balance design.
3.The PTFE filter cartridge with Filter Precision up to 0.3um.
4.Overall simple structure, easy to replace the filter device, simple operation.
5.Suitable for area: Chemical and pharmaceutical, food processing, metallurgy, casting, carbon materials, mechanical processing, building materials, mixing machine, cutting, mixing, stone engraving, machine plate processing, casting cutting, grinding, drilling, metal processing, bag sealing, air delivery inlet, crushing, mixing, etc. Cutting operation, powder putting operation, grinding machine operation.
Technical Parameter
Model | V1200(B) | V2000(B) | V2600(B) |
Power (KW) | 1.5 | 2.2 | 3.0 |
Voltage (V/Hz) | 380/50 | ||
Motor | Centrifugal fan | ||
Airflow (m3/h) | 1200 | 2000 | 2600 |
Vacuum (Pa) | 2100 | 2200 | 2400 |
Filtering area (cm2) | 200000 | 300000 | 400000 |
Filter quantity | 1 | 1 | 2 |
Filter Precision | 0.5μm >99.9% | ||
Pulse valves quantity | 1 | 1 | 2 |
Compressed air | 0.4~0.6MPa No oil, no water | ||
Noise level (dB) | ≤78 | ≤78 | ≤80 |
Machine weight (KG) | 150 | 200 | 260 |
Machine size (mm) | L550×W550×H1771 | L600×W600×H1890 | L800×W800×H1920 |
