Features
1.This series is equipped with 3 motors. The power can reach 1.5kw(24V battery powered) and 3.6kw(Single-phase);
2.Independent waterproof switch, one click start operation, with adjustable suction.
3.Reverse air path design. It can effectively compress the absorbed material and prevent clogging;
4.Star shape filter with filtering area up of 26800cm ², and it is washable and repeatable.
5.Barrel body is made of stainless steel metal material, strong bearing capacity, can adapt to different working conditions;
6.120L industrial large capacity dust bucket, high collection efficiency, with nylon collection bag, easy to clean;
Working Environment
Working place: Garment factory, textile factory, paper factory, knitting manufacturing, fiber manufacturing, etc
Suitable for absorbing lighter materials such as plastic debris, waste thread, flocs, paper scraps, cotton wadding, rags, flying flocs, etc.
Technical Parameter
Model | TM3D | TM3 | TM3B |
Voltage (V) | 24 | 220 | 220 |
Power (KW) | 1.5 | 3.6 | 3.6 |
Airflow (m3/h) | 306 | 495 | 495 |
Vacuum (mbar) | 115 | 230 | 230 |
Noise level (dB) | 67 | 67 | 67 |
Filter area (cm2) | 18800 | ||
Barrel capacity (L) | 120 | ||
Cable length (m) | / | 8 | |
Inlet (mm) | 40 | ||
Filter type | Star shape filter and Nylon filter bag | ||
Machine weight (kg) | 127 | 63 | 63 |
Machine size (mm) | 750*630*1130 |
